| General Radio |
Bluetooth Class 2, 20 meters (in open space)
Carrier Frequency : 2.4 ~ 2.483GHz
Data Rate : 1 Mbps
(The maximum operating range depends on the environmental factors.) |
| Bluetooth Standard |
Bluetooth v 1.2 & 1.1 |
| Spread Spectrum |
FHSS (Frequency Hopping Spread Spectrum) |
| Modulation Method |
GFSK (Gaussian Frequency Shift Keying) |
| I/O Interface |
USB v1.1 |
| Input Power |
DC 5V, USB Power |
| Sensitivity |
< 0.1% BER at -80 dBm |
| RF Output Power |
0 dBm (typical) |
| System Support |
Windows XP/2000/ME/98SE
(The product is driven by the bundled IVT BlueSoleil Bluetooth software or Windows XP SP2 Bluetooth stack) |
| Dimensions |
51.0 *16.0 *8.0 mm |
| LED Indicator |
Single LED |
| Advantage Functions |
Serial Port Profile
Dial Up Networking Profile
File Transfer Profile
Human Interface Device Profile
Hardcopy Cable Replacement Profile
Object Push Profile
Synchronization Profile
LAN Access Profile
FAX Profile
Personal Area Networking Profile
Advanced Audio Distribution Profile
Basic Imaging Profile |
| Boundled Bluetooth Software |
IVT BlueSoleil
(Language Supported: English, Simplified Chinese, Traditional Chinese, Japanese, Korean, French, Italian, German, Spanish) |
