| CPU |
Intel Atom N270 1.60 GHz
533 MHz Front Side Bus ( FSB ) |
| Memory |
DDR2 SDRAM socket x 1
1GB, up to 2GB |
| Chipset |
Intel 945GSE + ICH-7M |
| LCD |
LED backlight panel, clear type, 5.3mm
10.1” SWVGA, resolution 1024 x 600 |
| Storage |
SATA 2.5” HDD 5400rpm |
| Battery |
Li-ion rechargeable battery
3-cell, 3S1P, 2200mAh/2600mAh ( Battery life: 2hrs/2.5hrs )
Optional 6-cell, 3S2P, 2200mAh/2600mAh ( Battery life: 4hrs/5hrs )
|
| Audio |
Support amplifier and Mic.
2 x internal stereo speakers |
| Card Reader |
3-in-1 MS/SD/MMC |
| LAN |
10/100 Mb/sec. |
| Wireless LAN |
IEEE 802.11 b/g, Mini-PCIE interface |
| 3.5G |
Optional, mini-PCIE interface, WCDMA, SIM card slot is accessible in battery compartment |
| Webcam |
1.3M pixel |
| Keyboard |
80-key |
| Touchpad |
Touchpad with 2 buttons |
| AC Adapter |
19V, 40 Watts
|
| I/O Ports |
3 x USB 2.0
1 x VGA
1 x RJ45
1 x Headphone
1 x Mic in
1 x MS/SD/MMC card reader slot
1 x DC-in |
| LED indicator |
Caps Lock
Num Lock
Battery powe
WLAN on/off |
| BIOS |
AMI
Support PnP, ACPI 3.0 |
| O/S |
Support Windows XP, Linux FoxOS |
| Dimension |
250mm x 183mm x 19.5/28.8mm |
| Weight |
1.1 Kg with HDD & 3-cell battery |
| Cosmetic |
Painting on A covers
Optional Painting on A/C covers
Optional UV coating on A cover + painting on C cover |
| Option items |
Embedded 3.5G module, Mini PCIE interface
Bluetooth
HandBag |
